Recreating metafor forest plots in ggplot2

A step-by-step guide to reproducing the exact look of metafor’s forest() output using ggplot2.

Recently, I worked on a project comparing frequentist and Bayesian meta-analytic frameworks. In the paper I wrote about this (submitted) I wanted to have a figure with both forest plots side-by side with the only visual difference being that the Bayesian forest plot contains posterior distributions. While metafor’s forest() function does allow for some customization, adding posterior distributions is not possible. This post shows how to recreate the look of the metafor forest plot entirely in ggplot2, using posterior draws from a brms random-effects meta-analysis.

Let’s begin!

First, we load packages and read in the two fitted models — a Bayesian model fitted with brms and a frequentist model fitted with metafor. The frequentist model is used here only to extract the original study ordering, so the two plots are directly comparable.

library(brms)
library(metafor)
library(tidyverse)
library(tidybayes)
library(ggridges)
library(glue)
library(here)
library(magick)

m.brm <- readRDS(here("posts", "meta-analysis", "forestplot", "data", "m.brm_full.rds"))
freq_model <- readRDS(here("posts", "meta-analysis", "forestplot", "data", "freq_full.rds"))

Prepare data

Now we extract the posterior draws for each study-level effect using spread_draws() from tidybayes. r_author_year contains the study-level deviations from the overall pooled effect (b_Intercept), so we add b_Intercept to get each study’s absolute estimate on the outcome scale. We then do the same for the pooled estimate alone and bind both together into a single long data frame. The study labels are reordered to match the ordering in the frequentist model, with the pooled estimate placed at the bottom.

study.draws <- spread_draws(
  m.brm,
  r_author_year[author_year, ],
  b_Intercept
) %>%
  mutate(b_Intercept = r_author_year + b_Intercept)

pooled.effect.draws <- spread_draws(m.brm, b_Intercept) %>%
  mutate(author_year = "Pooled Estimate")

forest.data <- bind_rows(study.draws, pooled.effect.draws) %>%
  ungroup() %>%
  mutate(author_year = str_replace_all(author_year, "[.]", " ")) %>%
  mutate(
    author_year = factor(
      author_year,
      levels = c(rev(freq_model$data$author_year), "Pooled Estimate")
    )
  )

forest.data.summary <- group_by(forest.data, author_year) %>%
  mean_qi(b_Intercept)

To separate the pooled estimate visually from the individual studies, as metafor’s forest() does, we insert two blank spacer rows into the factor level ordering: one above and one below the individual studies. These levels appear on the y-axis but carry no data, so nothing is drawn at those positions. We also compute n_levels_total, which we need later to position the column headers and separator lines at the right y-coordinates.

n_studies <- nlevels(forest.data$author_year) # includes pooled estimate

study_levels <- setdiff(levels(forest.data$author_year), "Pooled Estimate")

new_levels <- c(
  "Pooled Estimate",
  "spacer_bottom",
  study_levels,
  "spacer_top"
)

forest.data <- forest.data %>%
  mutate(author_year = factor(author_year, levels = new_levels))

forest.data.summary <- forest.data.summary %>%
  mutate(author_year = factor(as.character(author_year), levels = new_levels))

# Append NA rows for the two spacer positions
spacer_rows <- tibble(
  author_year = factor(c("spacer_bottom", "spacer_top"), levels = new_levels),
  b_Intercept = NA_real_,
  .lower = NA_real_,
  .upper = NA_real_
)
forest.data.summary <- bind_rows(forest.data.summary, spacer_rows)

n_levels_total <- n_studies + 2

Set linewidth & font size

We set a few shared size constants before building the plot. base_size_theme controls text in theme() elements (in pts), while base_size_geom converts that to the different unit scale used by geom_text() and annotate().

linewidth <- 0.35
base_size_theme <- 12
base_size_geom <- base_size_theme * 0.352
title_size <- 14

Building the ggplot

Now we build the plot layer by layer. The dashed vertical line at x = 0 is drawn with annotate("segment") rather than geom_vline() because we need it to stop exactly at the top and bottom of the panel — geom_vline() would extend into the expanded margins. geom_density_ridges() draws the posterior distribution for each study and for the pooled estimate, using forest.data which contains all draws. geom_pointinterval() then overlays the mean and 95% credible interval on top, filtered to skip the spacer rows. geom_text() places the numeric summary to the right of the panel at a fixed x position; glue() formats each label as estimate [lower, upper].

The column headers (“Study” and “Estimate [95% CrI]”) and the two horizontal separator lines are all placed with annotate(), using n_levels_total as the y reference so they sit just above the top study row. clip = "off" in coord_cartesian() allows these annotations to extend beyond the panel boundary into the margin. In scale_y_discrete(), the spacer labels are suppressed by replacing them with empty strings in the labels function, and drop = FALSE keeps them in the ordering even though they carry no plotted data.

Bayes_forest_plot <- ggplot(
  aes(b_Intercept, author_year),
  data = forest.data
) +
  annotate(
    "segment",
    x = 0,
    xend = 0,
    y = 0,
    yend = n_levels_total,
    linewidth = linewidth,
    linetype = "dashed"
  ) +
  geom_density_ridges(
    fill = "grey",
    rel_min_height = 0.01,
    col = NA,
    scale = 1
  ) +
  geom_pointinterval(
    data = forest.data.summary %>% filter(!is.na(b_Intercept)),
    aes(xmin = .lower, xmax = .upper),
    shape = 22,
    point_fill = "black",
    fatten_point = 1.5,
    linewidth = 0.15
  ) +
  geom_text(
    data = mutate_if(
      forest.data.summary %>% filter(!is.na(b_Intercept)),
      is.numeric,
      round,
      2
    ),
    aes(
      label = glue(
        "{format(b_Intercept, nsmall = 2)} [{format(.lower, nsmall = 2)}, {format(.upper, nsmall = 2)}]"
      ),
      x = 3.5
    ),
    hjust = 0.2,
    size = base_size_geom
  ) +
  annotate(
    "text",
    x = -17.4,
    y = n_levels_total + 1,
    label = "Study",
    hjust = 1.05,
    fontface = "bold",
    size = base_size_geom
  ) +
  annotate(
    "text",
    x = 3.5,
    y = n_levels_total + 1,
    label = "Estimate [95% CrI]",
    hjust = 0.27,
    fontface = "bold",
    size = base_size_geom
  ) +
  annotate(
    "segment",
    x = -19.5,
    xend = 8,
    y = n_levels_total,
    yend = n_levels_total,
    linewidth = linewidth
  ) +
  annotate(
    "segment",
    x = -19.5,
    xend = 8,
    y = 2,
    yend = 2,
    linewidth = linewidth
  ) +
  labs(
    title = "Bayesian meta-analysis (ggplot2)",
    x = "Effect",
    y = NULL
  ) +
  scale_y_discrete(
    expand = expansion(add = c(0.5, 2.4)),
    labels = function(x) ifelse(x %in% c("spacer_bottom", "spacer_top"), "", x),
    drop = FALSE
  ) +
  scale_x_continuous(
    breaks = seq(-15, 5, by = 5),
    expand = expansion(add = c(2, 4))
  ) +
  coord_cartesian(
    xlim = c(-9.7, 5),
    clip = "off"
  ) +
  guides(x = guide_axis(cap = "both")) +
  theme_minimal() +
  theme(
    panel.border = element_blank(),
    panel.grid.major = element_blank(),
    panel.grid.minor = element_blank(),
    panel.background = element_blank(),
    plot.margin = margin(t = 18.5, r = 10, b = 35, l = 20),
    plot.title = element_text(hjust = 0, face = "bold", size = title_size),
    plot.background = element_rect(fill = "transparent", colour = NA),
    axis.text.y = element_text(
      hjust = 0,
      margin = margin(r = -10),
      size = base_size_theme,
      colour = "black"
    ),
    axis.text.x = element_text(vjust = -1, size = base_size_theme),
    axis.title.x = element_text(vjust = -2.7, size = base_size_theme),
    axis.line.x = element_line(linewidth = linewidth),
    axis.ticks.x = element_line(linewidth = linewidth),
    axis.ticks.length.x = unit(0.3, "cm"),
  )

Results

Okay, let’s now have a look and compare what we’ve built to the metafor forest plot!
